8
Small Block Ford Tru Trac - 13605 / 13625 9
Figure 3: Install Mounting Studs (Continued)
Thread the two 5/16-18 zinc coated hex nuts onto one of the studs and tighten
against each other to act as a drive nut (see illustration below*); then seat the
stud firmly into the block. Repeat this for the three remaining studs.
Remove zinc coated hex nuts and discard.
Apply anti seize to exposed stud threads at this time.
*Example
Figure 4: Prepare Timing Cover For Installation
Install oil pan end seal with a thin film of RTV silicone. If you were unable to
remove the oil pan install new corner gaskets at this time too.
