Figure 2-6. Connecting a network cable to the test bed
2.2.4 Connecting to the Device
Connect the serial data cable between the test bed and the serial device. If necessary, supply the
power to the serial device attached to the LS100M test bed.
Figure 2-7. Connecting a serial device to the LS100M
