Step 5. Turn off and on. Mode LED blinks twice in green every 3 seconds.
Step 6. Now SD1 is waiting for a connection from the last connected Bluetooth device. The last
connected Bluetooth device can connect to SD1.
Table 3-7 Pairing Process with other Bluetooth device by Pairing Button
SD1 Status LED Other Bluetooth Device Status
1. Factory reset Mode0 Mode LED turns on
2. Push pairing button Mode3 Mode LED blinks 3 times
every 3 seconds
3. Inquiry and connect to SD1
4. Connected Slave Connect LED blinks
every second
4. Connected Master
And SD1000 is support multi-connection type of Multi-Drop Mode. SD1000 is support 1:4 multi-
connection. In this example we will refer to the four Parani-SD1000s (one master, four slaves) as
master and slave1, slave2, slave3, slave4.
Step 1. Turn on master and reset it by pressing Factory Reset Button. And turn on slave1, slave2,
slave3, slave4 and reset it by pressing Factory Reset Button.
Step 2. Press the Pairing Button of slave1, slave2, slave3, slave4 for 2 seconds until Mode LED blinks
3 times every 3 seconds. Keep the power ON.
Step 3. Press the Pairing Button of master for 2 seconds until Mode LED blinks 3 times every 3
seconds. Keep the power ON.
Step 4. Press the Pairing Button of master for 2 seconds until Mode LED blinks every second. Wait for
master & slave1 to connect to each other until the Connect LED‟s of master and slave1 blink every 1
second. It takes about 10 seconds to make a connection. If there are many Bluetooth devices
nearby, it may take longer. And slave1‟s address is save to master‟s S-Register 46.
Step 5. Press the Pairing Button of master for 2 seconds. Then master is reset for multi-drop mode.
And master is disconnected to slave1. And master‟s Mode LED blinks 3 times every 3 seconds. Wait
for master & slave1 to connect to each other until the Connect LED
‟s of master and slave1 blink
every 1 second. It takes about 10 seconds to make a connection. If there are many Bluetooth
devices nearby, it may take longer.
Step 6. Press the Pairing Button of master for 2 seconds until Mode LED blinks every second. Wait for
master & slave2 to connect to each other until the Connect LED‟s of master and slave2 blink every 1
second. It takes about 10 seconds to make a connection. If there are many Bluetooth devices
nearby, it may take longer. And slave2‟s address is save to master‟s S-Register 54.
Step 7. Press the Pairing Button of master for 2 seconds until Mode LED blinks every second. Wait for
master & slave3 to connect to each other until the Connect LED‟s of master and slave3 blink every 1
second. It takes about 10 seconds to make a connection. If there are many Bluetooth devices
nearby, it may take longer. And slave3‟s address is save to master‟s S-Register 55.
Step 8. Press the Pairing Button of master for 2 seconds until Mode LED blinks every second. Wait for
mast er & slave4 to connect to each other until the Connect LED‟s of master and slave4 blink every 1
second. It takes about 10 seconds to make a connection. If there are many Bluetooth devices
nearby, it may take longer. And slave4‟s address is save to master‟s S-Register 56. After slave4 is
connected to master, pressing the Pairing button of master is ignored.
Step 9. If turn off master or slaves and turn on it, multi-drop mode is maintained.
Table 3-8 Process of Multi-Drop Mode by Pairing Button
master Status LED Slave Status LED
1. Factory reset Mode0 Mode LED turns on
2. Slave 1
Factory reset Mode0 Mode LED turns on
