PX-2 Installation and Operation Instructions
2 110-00000-000-01-201009
Parts Included
The PX-2 ships with the following items:

PX-2 Pulsed Xenon Light Source

12 VDC power adapter

15-pin interface cable
Additional Accessories
The following are additional accessories available from Ocean Optics that you may need, depending
on your system set-up:
 USB2000/PX-2 adapter (USB-ADP-PX2)
 Replacement bulb (PX-2-B)
WARNING
The PX-2 produces ultraviolet radiation. Direct eye contact can cause permanent
eye damage. Always wear safety eyewear, and never look directly into the light
source.
Dangerous voltages are present in the PX-2. Do not operate the PX-2 without the
housing intact.
The SMA 905 Connector can get hot during operation. Allow the lamp to cool
after operation before handling.
Do not drop the instrument, as this may cause permanent damage to the unit.
Handle with care.
Connecting the PX-2
The set-up procedure differs, depending on the spectrometer to which you are connecting the PX-2.
Connecting to an S2000 Spectrometer
► Procedure
1. Remove the PX-2 from the product packaging.
2. Plug the 12 VDC power supply into a wall outlet, then connect the barrel connector on the
power supply to the rear of the PX-2.
3. Connect the 15-pin cable to the rear of the PX-2, and then connect the other end to the 15-pin
connector on the S2000 Spectrometer.
You have now connected the PX-2 for operation with the S2000 Spectrometer.
