LIBS Imaging Module Installation and Operation Instructions
Operating the LIBS Imaging Module
► Procedure
1. Focus the image on the screen.
2. Fire the laser at the sample.
3. Adjust the mirror’s three knobs after firing laser at target to ensure that the laser spot is in the
center of the image.
4. Close the front door of the LIBS Imaging Module.
5. Fire the laser.
6. Start your experiments.
Specifications
Specifications Criteria
Physical Dimensions
Weight 305 mm x 146 mm x 127 mm
3.68 kg
Power Consumption 250 mA at 12 VDC (supplied by PC FireWire card)
Sample Image Resolution:
Black and white camera
Color camera
40 microns
60 microns
Operating Temperature +5 o to +60 o C
Camera Specifications:
Resolution
Pixel Size
Frame Rate
1280 x 1024 active pixels
6.0 um x 6.0 um, square
Up to 12.7 fps at 180 x 1024 resolution
