Ventana Data Sheet
891-00000-200-05-201305 3
Specifications
CCD Detector Specifications
Specification Ventana 532 Ventana 785 Ventana 785L Ventana Vis/NIR
Detector Hamamatsu S11510-1006 Back-thinned NIR-enhanced CCD Hamamatsu
S10420-1006 Back-
thinned CCD
Detector
active area
(mm) 14.336 x 0.896
Pixel format 1024 x 64
Pixel size 14 µm square
Well depth 300 Ke
-
Read noise 6 e- RMS
Dynamic
range 17000:1 (Typical)
CCD QE 78% peak, 60% average in Raman 75% peak
CCD Cooling None 15 ° C None
Ventana Spectrometer Specifications
Specification Ventana 532 Ventana 785 Ventana 785L Ventana VIS/NIR
Dimensions
(LxWxH)
170 mm (6.7 in.) x
110 mm (4.3 in.) x
50 mm (1.9 in.) 125 mm (4.9 in.) x
110 mm (4.3 in.) x
50 mm (1.9 in.)
127 mm (5 in.) x
158.75 mm (6.25
in.) x 50.8 mm (2
in.)
170 mm (6.7 in.) x
110 mm (4.3 in.) x
50 (1.9 in.)
Weight 0.9kg (2 lb)
Spectrometer:1.2kg
(2.6 lb)
Power Supply:
0.5kg (1.10 lb)
0.9kg (2 lb)
Temperature
Operation
0 to 50 ° C (noncondensing)
5 to 45 ° C
(noncondensing)
0 to 50 ° C
(noncondensing)
