Ventana Data Sheet
2 891-00000-200-05-201305
In addition to the Ventana spectrometers, the Ventana-785-Probe offers a Raman-coupled fiber probe
for 785 nm excitation; FC connector (excitation), SMA connector (collection); 11.0 mm working
distance; 250-2000 cm-1; comes with 600 µm 0.39 NA detection and 100 µm 0.22 NA excitation
fibers to maximize sensitivity.
Features
• HD Volume Phase Holographic (VPH) Grating
• Electrical Performance
• 16 bit A/D converter
• Communications: USB
• Software compatibility:
• OceanView (1 complimentary license included with purchase)
• SpectraSuite
• OmniDriver (sold separately)
• USB Programmer (available free from Ocean Optics)
• SeaBreeze (sold separately)
• Optical input: SMA 905
• Regulations:
• CE Mark
• RoHS
