2: Programming Information
000-10000-150-02-201011 7
MONO_SetPosition
short __stdcall MONO_SetPosition(long Handle,unsigned short Node,long Position);
call this function to set an absolute user defined position. Wavelength is not linear to position
Returns 0 in case of error else 1
long Handle: Handle of the comport returned by MONO_OpenConnection
unsigned short Node: must be 0 (zero)
long position: absolute position value
MONO_GetPosition
long __stdcall MONO_GetPosition(long Handle,unsigned short Node);
call this function to get the absolute position in steps (arbitrary unit)
long Handle: handle of the comport returned by MONO_OpenConnection
unsigned short Node: must be 0 (zero)
Direct Serial Communication (ASCII Commands)
If you do not want to use the DLL-functions you can directly communicate with the MonoScan2000
using ASCII commands.
► Procedure
The following steps are required:
1. Establish serial connection from PC to MonoScan-2000
2. Read device information such as calibration data and serial number (not necessarily needed)
3. Set an absolute position. Repeat this step as needed.
4. Close serial connection
ASCII Commands
Command Description Example
GOHOSEQ Reference run is executed. Runs to the lower endpoint
(approx 200nm) and sets this position to 0 (zero) GOHOSEQ [CR]
LA Sets absolute position in steps
Command M starts positioning LA-5000 [CR]M [CR]
LR Sets relative position in steps
Command M starts positioning LR100 [CR]M [CR]
POS Returns actual position in steps POS [CR]
