Ocean Optics HL-2000-FHSA User Manual
Page 22
A: Bulb Replacement
14
000-10000-070-02-201307
9. Slide the electronics board back into the HL-2000-FHSA, taking particular care to ensure that the
wires do not come into contact with the fan blades.
Figure 5: HL-2000-FHSA Bulb Replacement Diagram
Rear / Electronics Board
Connection
Block
Lamp
Housing
Fan Wires
