1: Setup
2 000-10000-070-02-201307
2. Inspect the outside of the instrument and make sure that there is no damage. Do not use the
instrument if damage is present. Contact your dealer for repair or replacement information, if
necessary.
3. Use this instrument in a clean laboratory environment.
Contents
Your HL-2000-FHSA package should contain the following:
 HL-2000 Light Source
 One IC-DB15-2 interface cable for shutter operation
Setting Up the HL-2000-FHSA Light Source
Use the following procedure and refer to HL-2000-FSHA Diagrams to set up your light source.
►
Procedure
Perform the steps below to set up your HL-2000-FHSA Light Source:
1. Plug the power supply into a wall outlet.
Power Supply
2. Plug the other end of the power supply cable into the socket of HL-2000-FHSA.
