Pinout information – Ocean Optics HL-2000-FHSA User Manual
Page 18
2: HL-2000 Specifications
10
000-10000-070-02-201307
Pinout Information
The following table contains pinout information for the HL-2000-FHSA Light Source:
Pin
Description
1
na
2
na
3
na
4
na
5
na
6
na
7
na
8
na
9
na
10
Ground
11
na
12
na
13
TTL Signal – Shutter control
14
na
15
na
na = not applicable
