Ocean Optics PinPointer User Manual
Page 16
Page 15
CLASS III b LASER PRODUCT
AVOID DIRECT EXPOSURE TO BEAM
RSIQ™ Spectroscopy Software
Please refer to the separate User’s Manual for RSIQ spectroscopy software to learn
about its many features.
RSIQ is accessed from the ID
-find™
GUI by touching the
Advance icon
The version of RSIQ loaded on the PinPointer has been slightly modified. The
PinPointer GUI is designed for portrait orientation on the LCD screen, rather than the
landscape orientation as normal for desktop LCD monitors. An example is below:
