Specifications: ls-1 and r-ls-1 – Ocean Optics LS-1 Series User Manual

Page 11

LS-1 Installation and Operation Instructions

009-00000-STD-01-201010

Specifications: LS-1 and R-LS-1

LS-1

R-LS-1

Spectral range:

360-2000 nm

If used with an Ocean Optics spectrometer, the practical spectral range of

the light source is limited to the spectral response of the detector.

Dimensions:

113.5 mm x 50.8 mm x 31.6 mm

Weight

140 grams

Power input:

12 VDC / 800 mA

7-20 VDC / 0.5-2 amps

Power output:

6.5 watts

Bulb life:

900 hours (standard)

10,000 hours (long life)

Bulb color temperature:

900-hour bulb – 3100K

10,000-hour bulb – 2800K

Output to bulb:

5 volts / 1.3 amps

Output regulation:

0.2% voltage

Time to stabilized output:

~30 minutes

Bulb output:

7400 foot-candles (7.4 MSCP)

Connector:

SMA 905
