A: ASCII Commands
12 000-10000-140-02-201307
Command Function Description Example
HL Home Limit Action This command is used to set the action that
occurs when the limit switch is activated. If HL
is set to 0, the motor will continue to run after
switch activation but will send an "h" message
signifying home switch was triggered. If HL is
set to 1, the motor will stop immediately after
switch activation. HL 1
HN Hard Notify If HN is set to 1, it configures the motion
controller to send a serial message "h" once the
external limit switch is triggered. HN 1
HP Define External Switch
Polarity This command defines the activation edge of
the external switch. If HP is 0 a falling edge at
the external limit switch is valid. If HP is 1 a
rising edge occurs actions due to HL, HN and
HA-commands. HP 0
HS External Switch Status This command returns the state of the limit
switch. If the limit switch was active and an HS
request is sent, the controller will return a 1. If
the limit switch was not active since a HL, HN
or HA-command was sent an HS request will
return a 0 to the host. HS
Commands That Return Data
Command Function
Description Example
GV Get Velocity
Commanded This command returns the command velocity
sent. GV
GN Get Actual Velocity This command returns the actual velocity. GN
GI Get Integral Term This command returns the Integral gain setting. GI
GCL Get Current Limit This command returns the present current limit. GCL
POS Get Present Position This command returns the present motor
position. POS
TEM Get Temperature This command returns the present coil
temperature (in °C) TEM
GAC Get Acceleration This command returns acceleration GAC
GSP Get Maximum Speed This command returns Maximum speed setting. GSP
