000-10000-180-02-201401

Appendix A

Bulb Replacement

Overview

The following sections provide instructions on changing the krypton bulb in the ecoVis. To order
replacement bulbs for the ecoVis, order item number ECOVIS-B.

Note

Do not directly touch the glass of the bulb with your fingers. Use a cloth or gloves with a
surface which is free of grease and sweat.

Replacing the Bulb

WARNING

The lamp and especially the light bulb could be hot. Wait until the ecoVis has cooled
down to ambient temperature before attempting to change the bulb.

►

Procedure

1. Unplug the AC adapter from the ecoVis.

2. Use the Allen wrench to loosen the stud screw from the bottom of the ecoVis.
