Chapter 2
ecoVis Specifications
This section provides information on the operating environment, physical controls, and dimensions of the
ecoVis.
Specifications Criteria
Wavelength Range 400 – 2500 nm
Drift < 0.5 % per hour
Time to Stabilize Approximately 10 minutes
Power Supply Input 100-240 V / 50-60 Hz / 150 mA
Power Supply Output 3.5 Vdc / 1100 mA
Bulb Lifetime 2000 hours
Color Temerature 2400K
Characteristic focused / SMA905 connector
Cuvette Holder Path Length 10 mm
Cuvette Holder z Dimension 15 mm
Temperature
Housing
Environment
42 °C @ 25 °C ambient
5°C – 35°C
Humidity 5 - 95% at 40°C
Lamp Power 1.3 W
Weight 272 g (0.6 lbs.)
Dimensions 50 mm x 95 mm
Parts List
Description Part Number
Krypton Light Source, passive cooled EcoVis
Krypton spare bulb Eco-Vis-B
