15 WATER SUPPLY CONNECTIONS

Connect water Supply Lines (15A) to Faucet Inlets (15B). Hot water supply

line goes to hot inlet fi tting indicated by Tag (15C). (Supply lines not included).

Follow manufacturer’s instructions when installing supply lines.

16 UNIT START UP

Turn on hot and cold water supplies, and check for leaks above and below the

sink.

Note: After installation is complete, fl ush faucet (see step 21).

17 SPOUT FUNCTION

Spout (17A) can be rotated around the Faucet Body in any direction.

18 VALVE FUNCTION

By lifting Lever Handle (18A) up, the valve will be activated allowing water to

fl ow. The water fl ow will increase by continuing to lift up Lever Handle (18A).

By rotating Lever Handle (18A) counterclockwise, the water temperature will

decreased to fully cold. By rotating Lever Handle (18A) clockwise, the water

temperature will increased to fully hot.

19 SIDE SPRAY OPERATION

Side Spray (19A) can be pulled out to spray water in any direction. To activate

the Side Spray (19A), press Toggle Button (19B) located on the back of Side

Spray (19A).

20 SOAP DISPENSER OPERATION

To activate Soap Dispenser (20A), press Dispenser Head (20B) to dispense

liquid soap.

5

FAUCET FUNCTIONS

18A

15A

19A

17A

20A

15C

15B

15B

15A

18A

HOT

COLD

HOT

COLD

ON

19B

20B
