Frame preparation – Factory Direct Hardware Von Duprin 9947WDCEOF User Manual

Page 4

background image

6

5

5

Offset link

Secure latches and rods into door

as shown and attach offset links.

Top latch

& rod

Bottom latch

& rod

G

F

Lock nut

Install blocking and door wrap

(if using door wrap).

Blocking

See page page 7 for blocking dimensions

NOTE: If not using door wrap, the blocking can be

installed after device is installed.

Blocking

Door wrap

Optional- to be used on fire doors only,

not supplied by Von Duprin

1

2

Draw horizontal and vertical

device center lines (C ).

L

RHR shown

(LHR opposite)

39 -9/16”

to bottom

of

door

Align template along center lines

and mark holes and cut-outs.

CL

CL

CL

2-1/2”

backset

CL

CL

CL

9

4

CL

338 Top strike

Ratchet release

7/16”

1-1/8”

9/16”

#25 Drill

#10-24 tap,

2 places

Latch case

Plunger must go thru

hole in door.

Adjust so plunger

releases latch bolt when

door is closed.

Reinforcing

required

Plunger

15/16”

Inside

beveled

edge

6” min.

1” min.

1/8”

Edge of stop

1-5/16”

21/32”

13/32”

15/16”

1-7/8”

Inside

beveled

edge

13/16”

13/32”

1/4” dia.

82

°

csk. x 3/8”

dia. in frame

Double door application

Latch bolt LHR door

Latch bolt RHR door

CL

CL

CL

FRAME PREPARATION
