Model 38117XX1 only:
Measure the distance between the wall surface and
the end of the handle (x).
If x is between 3 1/4” and 3 7/8”, select the two
“A” sleeves (1 1/4”).
If x is between 3 7/8” - 4 3/8”, select the two “B”
sleeves (7/8”).
If x is greater than 4 3/8”, select the two “C” sleeves
(1/”).
x
A
B
C
1 1/4”
7/8”
1/
”
