Factory Direct Hardware Hansgrohe 38117 User Manual
Page 13
13
1 flange
608XX0
handle
100XX0
3 escutcheon for handle
61XX0
4 escutcheon for spout
613XX0
baseplate
614XX0
6 cartridge cpl.
633000
7 aerator cpl.
611XX0
8 fixing set
771000
escutcheon for spout
610XX0
10 escutcheon for handle
60XX0
11 extension set (not included)
388000
XX = color
00 = chrome
8 = brushed nickel
Replacement Parts
38118XX1
6
7
8
1
10
11
