Measure the distance from the rough to the outside
surface of the finished wall (X) (1).
Add 1” to X. Cut the threaded end of the spout so that
it is X + 1” long ().
Install the spout escutcheon on the spout. Push the
sealing ring into the spout escutcheon.
Wrap the threads on the spout with Teflon tape (1).
Install the spout ().
1.
2.
1.
2.
