5
Exception:
If the software for the CCD linear camera
(1013311) and/or spectrophotometer (1003160) has
already been installed onto the computer, follow
the instructions below:
• Connect 3B NETlog™ to the computer via the
USB cable.
The computer will not report that a new hardware
has been detected.
• Insert the installation CD into the CD-ROM
drive of the computer.
Windows 2000:
• System control panel
-> System -> Hardware ->
open Device manager.
• Double-click USB controller.
• Double-click “ULICE USB Product”.
• Click Driver -> Update driver. (The wizard for
updating the device driver will start.)
• Select “Show all known drivers from list and
search for the suitable/appropriate driver”.
• Select “Drive” and then “Search” to establish
the path to the driver.
• Click “Yes” to confirm that the file should be
overwritten.
Windows XP:
• System control panel -> System -> Hardware ->
open Device manager.
• Double-click on USB controller.
• Double-click “ULICE USB Product”.
• Click Driver -> Update driver. (The hardware
assistant will start.)
• Do not activate Windows Update.
• Select “Install software from specific source”.
• Select “Do not search. Autodetect driver”.
• Select “Drive” and then “Search” to establish
the path to the driver.
• Click “Yes” to confirm that the file should be
overwritten.
• Click “Proceed with installation” when the
hardware message states that the software has
failed to pass the Windows Logo Test.
7.2 Software installation
Note on installing the software
For this software, please refer to the installation
instructions available in the 3B NETlab™ software
manual.
8. Operating without a computer
Operating a 3B NETlog™ device without a computer
is achieved by using the buttons on the operating
panel. The functions of these buttons may change
according to the operation being undertaken.
Note: a menu selection can be cancelled at
any time by using the
Channel
← button.
8.1 Battery level and temperature display
• Switch on the 3B NETlog™ device by pressing
the On/Off button.
• Press the Date/Time
↵ button.
The following should appear on the display:
e.g.: BATTERY: 100%
TEMP.: 22.0°C
8.2 Setting the time
• Switch on the 3B NETlog™ device by pressing
the On/Off button.
• Press the Date/Time
↵ button twice (the time
field will appear on the display).
• Press the Store
↓ button (the input field for SET
TIME will appear on the display).
• Specify the desired time in the input field by
pressing the Rate
↑ or the Store ↓ button and
use the Channel
← button to skip between the
hours, minutes and seconds fields.
• Confirm by pressing the Date/Time
↵ button.
8.3 Setting the date
• Switch on the 3B NETlog™ device by pressing
the On/Off button.
• Press Date/Time
↵ button three times (the date
field will appear on the display).
• Press the Store
↓ button (the input field for SET
DATE will appear on the display).
• Specify the desired date in the input field by
pressing the Rate
↑ or the Store ↓ button and
use the Channel
← button to skip between the
year, month and day fields.
• Confirm by pressing the Date/Time
↵ button.
8.4 Application as a handheld device for meas-
uring current and voltage
• Set up the 3B NETlog™ equipment.
• Connect the voltage/current input of channel A
or B, as desired.
• If necessary, disconnect any sensor which
might be connected to the same channel.
