Specifications
Inputs
Connectors:
1/4” TRS, female XLR (pin 2 hot), and Euroblock
Type:
Electronically balanced/unbalanced, RF filtered
Impedance:
Balanced 40kΩ, unbalanced 20kΩ
Max Input Level:
+22dBu balanced or unbalanced
CMRR:
>40dB, typically >55dB at 1kHz
Outputs
Connectors:
1/4” TRS, male XLR (pin 2 hot), and Euroblock
Type:
Balanced/unbalanced, RF filtered
Impedance:
Balanced 120Ω, unbalanced 60Ω
Max Output Level:
+20dBu balanced/unbalanced into 2kΩ or greater
System Performance
Frequency Response:
20Hz to 20kHz, +0�5/-0�25dB
Dynamic Range:
>113dB, “A” weighted
THD+Noise:
0�003% typical at +4dBu, 1kHz
Interchannel Crosstalk:
<-80dB, 20Hz to 20kHz
Noise Reduction:
Up to 10dB of dynamic broadband noise reduction
Digital Resolution:
24 bits
Sample Frequency:
48kHz
Latency:
2msec
Function Buttons
AFS™:
Activates dbx AFS™ Advanced Feedback Suppression
TYPE V™ NR:
Activates dbx Type V™ Noise Reduction
EQ Bypass:
Bypasses the graphic equalizer section in the signal path
Low Cut:
Activates the 40Hz 18dB/octave Bessel high-pass filter Range
Range:
Selects either +/- 6dB or +/- 15dB slider boost/cut range
Indicators
Output Level:
4-LED bar graph (Green, Green, Yellow, Red) at -10, 0, +10, and +18dBu
Gain Reduction:
4-LED bar graph (all Red) at 0, 3, 6, and 10dB
Type V™ NR:
1 LED: yellow, green or red
EQ Bypass:
1 LED: red
Clip:
1 LED: red
Low Cut:
1 LED: red
+/-15dB:
1 LED: red
Power Supply
Operating Voltage:
120VAC 60Hz, 220-240VAC 50/60Hz
Power Consumption:
17 Watts
Mains Connection:
IEC receptacle
Physical
Dimensions:
iEQ-15: 3�5” (H) X 19” (W) X 7�9” (D) (8�9cm x 48�3cm x 20�1cm)
iEQ-31: 5�25” (H) X 19” (W) X 7�9” (D) (13�4cm x 48�3cm x 20�1cm)
Weight:
iEQ-15: 7�5 lbs�
iEQ-31: 9�25 lbs�
Shipping Weight:
iEQ-15: 8�5 lbs�
iEQ-31:
10�25
lbs�
NOTE: Specifications subject to change�
