NWP-2520
EN-2389
REV A
We recommended installation of this product by a Professional Plumbing Contractor
Note: The use of petroleum base plumbers putty on our products will nullify the warranty. We recommend
the use of clear silicone sealing materials. Recommended deck hole Ø1-3/8” and Ø1-3/16” for two
side holes.
1. Place the SPOUT (1) hoses, one at a time, and threaded ROD (2) through center hole of mounting sur-
face. Secure SPOUT (1) into place with BRACKET (3) and NUT (4). See Figure 1.
2. Place flange NUT (6) and SPACER (5) on valve BODY (7). Insert valve BODY (7) through the hole in the
mounting surface. Adjust and secure with INVERTED NUT(8) so that the top of VALVE (7) is 5/16" above
the top of mounting surface. Before tightening INVERTED NUT (8), check alignment of handle. Any adjust-
ments for rotational alignment must be made to the valve BODY (7), not to the cartridge. See Figure 1&
Figure 2.
3. Connect the loose end of flexible HOSE (9) to side outlet of valve BODY (7). (Hand-tighten and secure
each connection with a wrench ¼ turn.) Repeat on other side. See Figure 2.
4. Connect hot/cold water supply to appropriate 1/2” NPSM valve BODY (7), utilizing one of the three fol-
lowing types of risers. Supply risers not included. See Figure 3.
a. 1/2” IPS flexible riser: discard rubber nosecone WASHER (11), friction WASHER (12) and coupling NUT
(13).
b. 3/8” or 1/2” OD bullnose riser: utilize friction WASHER (12) and coupling NUT (13).
c. 1/2” copper riser: utilize rubber nosecone WASHER (11), friction WASHER (12) and coupling NUT (13).
5. Secure HANDLE (14) into place by first engaging the STEM (16) and then threading ESCUTCHEON (17)
onto CARTRIDGE (15). Any adjustments for rotational alignment must be made to the valve BODY (4), not
to the CARTRIDGE (15). See Figure 4.
6. Remove drain PLUG (18) from FLANGE (19). Place FLANGE (19) and white WASHER (20) through sink drain
opening. (Clear silicone may be used in place of white washer.) From bottom side of sink, place cone
shaped rubber WASHER (21) onto FLANGE (19) and slide up against sink bottom. Note: Cone portion of
washer should face upward. Next slide on clear flat WASHER (22) and secure with flange NUT (2). Place
clear WASHER (25) into drain BODY (23) and tighten to FLANGE (19). Apply thread sealant to TAILPIECE
(24) and attach to drain BODY (23). Attach TAILPIECE (24) to p-trap drain, not included. See Figure 5.
7. Insert ball ROD (29) into the drain rod OPENING (30); secure with ball rod NUT (31). Insert pop-up ROD
(26) through SPOUT (1) and secure to STRAP (27), approximately 1" from end of ROD (26), with SCREW
(28). Place drain PLUG (18) into FLANGE (19). Adjust the rise of the plunger and CLIP (32) into place.
Adjust ball ROD (29) and pop-up ROD (26) so drain will open and close properly. See Figure 6.
8. Remove AERATOR (33) from SPOUT (1), utilizing aerator KEY (34). Turn on water supply, and flush both
VALVES (4) until water is clear. Check for leaks and make any final adjustments required. Re-attach AER-
ATOR (33) to the SPOUT (1) using aerator KEY (34). See Figure 6.
