Newport Brass 1-560 User Manual
Page 2
NWP-1-560
REV-
Finished Wall Dimension
1-7/8” MIN
4-5/8” MAX
5
Figure 1A
Handle
Adapter
Finished Wall
Vertical
Stud Face
Cartridge Bonnet
5/8” Hex
Hot Inlet
1/2” NPT
STEM
All Thread
Cold Inlet
1/2”COPPER SWEAT (5/8” DIA)
1/2” NPT
1
2
4
3
Figure 1
01/25/2013
EN-2446
2001 CARNEGIE AVE, SANTA ANA CA 92705
(949) 417-5207
WWW.NEWPORTBRASS.COM
