3. Remove the metal retainers from the rubber blade
and install them in the new rubber blade.
Maintenance
7-30
4. Carefully insert a new rubber blade and re-install
the blade assembly in the reverse order of removal.
Install the blade with the tabs facing towards the
bottom of the wiper arm.
✻
✻
NOTICE
Do not bend the metal retainers.
AN7B07018
AN7B07019
Retainer
Retainer
