Peerless-AV DS-VWS546-2X2 - Installation - Manual (Page 3)

3 of 11 ISSUED: 01-16-13 SHEET #: 125-9398-1 01-16-13
Parts List
Part Description Quantity Part Number
A clamp 4 145-1734
B FPZ-600 base 2 201-1037
C FPZ-600 main tube 4 580-1159
D fender washer 12 540-1008
e M6 x 40mm phillips screw 12 520-1584
F set screw 8 520-9566
g bumper strip 2 570-1030
h security wrench 1 560-9646
I wall plate 2 145-1342
j left bracket 1 145-1345
k right bracket 1 145-1344
L hook on bracket 4 145-1356
M top bracket 4 145-1347
N bottom bracket 4 145-1348
O M6 x 12mm phillips screw 16 520-1128
P M8 x 15mm phillips screw 16 520-9257
q nylon shoulder washer 16 590-2233
R M5 x 10mm socket pin Type-F screw 8 520-1164
S M5 x 12mm phillips screw 40 520-1027
T cable tie 8 560-9711
U mesh sleeve 4 600-1014
V #10 lock washer 8 540-1035
W #10 flat washer 8 540-9400
X measure plate 1 145-1349
Y M6 x 16mm phillips screw 16 520-9274
Before beginning, make sure you have all parts shown below
