Use detail 3 to figure adapter bracket ( B) placement.
8
Attach adapter brackets ( B) to back of display using four M6 x 12 mm phillips screws (O) with nylon shoulder
washer [ 4mm] (L), or four M8 x 15 mm phillips screws (N) as shown below.
Adapter Bracket Mounting Patterns
Adapter Bracket Placement Detail
8.1
400 mm
300 mm
200 mm
200 mm MIN
600 mm MAX
43.65"
(1109 mm)
68.25"
(1733 mm)
MAX MIN
33.50"
(850 mm)
MIN
47.50"
(1206 mm)
MAX
DISPLAyS NOT SHOWN FOR CLARITy
DETAIL 3
MAX HOLE
PATTERN
MIN HOLE
PATTERN
MIN HOLE PATTERN
MAX HOLE PATTERN
B
O or N
L
PLP PLATE
