Peerless-AV PRG-EXC-W - Installation - Manual (Page 3)

3 of 14 ISSUED: 04-24-08 SHEET #: 055-9257-7 07-15-11
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112
extendable outer channel (BB) inner channel (CC) cable cover (LL)
Model# length part# part# part#
PRG-EXA 8.69" - 12.79" 055-1779 055-1778 055-1809-2
PRG-EXA-S 8.69" - 12.79" 055-4779 055-4778 055-4809-2
PRG-EXA-W 8.69" - 12.79" 055-2779 055-2778 055-2809-2
PRG-EXB 12.69" - 20.69" 055-1776 055-1775 055-1809-1
PRG-EXB-S 12.69" - 20.69" 055-4776 055-4775 055-4809-1
PRG-EXB-W 12.69" - 20.69" 055-2776 055-2775 055-2809-1
PRG-EXC 19.14" - 32.9" 055-1770 055-1769 055-1809
PRG-EXC-S 19.14" - 32.9" 055-4770 055-4769 055-4809
PRG-EXC-W 19.14" - 32.9" 055-2770 055-2769 055-2809
OUTER CHANNEL, INNER CHANNEL AND CABLE COVER
PART NUMBER CHART
PRG-EXA
PRG-EXB PRG-EXA-S
PRG-EXB-S PRG-EXA-W
PRG-EXB-W
PRG-EXC PRG-EXC-S PRG-EXC-W
Description Qty. Part # Part # Part # Part # Part # Part #
A projector mount assembly 1 054-1171 054-4171 054-2171 054-1171 054-4171 054-2171
B adapter plate 1 055-1938 055-4938 055-2938 055-1938 055-4938 055-2938
C concrete anchor 2 590-0320 590-0320 590-0320 590-0320 590-0320 590-0320
D #14 x 2.5" phillips hex head wood screw 2 5S1-015-C03 5S1-015-C04 5S1-015-C04 5S1-015-C03 5S1-015-C04 5S1-015-C04
E #10-32 x 1/4" socket pin screw 1 520-1196 520-2196 520-2196 520-1196 520-2196 520-2196
F 1/4" flat washer 6 540-1078 540-2078 540-2078 540-1078 540-2078 540-2078
G #6 flat washer x .5 OD 4 540-1025 540-2025 540-2025 540-1025 540-2025 540-2025
H 2 mm security allen wrench 1 560-1097 560-1097 560-1097 560-1097 560-1097 560-1097
I 4 mm security allen wrench 1 560-9646 560-9646 560-9646 560-9646 560-9646 560-9646
J M3 x 8 mm serrated washer head socket pin screw 4 510-1004 510-2004 510-2004 510-1004 510-2004 510-2004
K M4 x 10 mm serrated washer head socket pin screw 4 510-1060 510-2060 510-2060 510-1060 510-2060 510-2060
L M5 x 10 mm serrated washer head socket pin screw 4 510-1126 510-2063 510-2063 510-1126 510-2063 510-2063
M M6 x 10 mm serrated washer head socket pin screw 4 510-1066 510-2066 510-2066 510-1066 510-2066 510-2066
AA ceiling plate 1 055-1773 055-4773 055-2773 055-1773 055-4773 055-2773
BB o ter channel 1 SEE CHART SEE CHART SEE CHART SEE CHART SEE CHART SEE CHART
Parts List
BB outer channel 1 SEE CHART SEE CHART SEE CHART SEE CHART SEE CHART SEE CHART
CC inner channel 1 SEE CHART SEE CHART SEE CHART SEE CHART SEE CHART SEE CHART
DD clamp plate 1 055-1771 055-4771 055-2771 055-1771 055-4771 055-2771
EE vertical mounting plate 1 055-1876 055-4876 055-2876 055-1876 055-4876 055-2876
FF horizontal mounting plate 1 055-1787 055-4787 055-2787 N/A N/A N/A
GG M5 x 16 mm socket pin screw 2 520-1161 520-2161 520-2161 520-1161 520-2161 520-2161
HH M6 x 12 mm socket pin screw 2 520-1050 520-2050 520-2050 520-1050 520-2050 520-2050
II M6 x 10 mm socket pin screw 4 520-1066 520-2066 520-2066 520-1066 520-2066 520-2066
JJ M5 x 10 mm socket pin screw 4 520-1063 520-2063 520-2063 520-1063 520-2063 520-2063
KK serrated locknut 2 530-1027 530-2042 530-2042 530-1027 530-2042 530-2042
LL cable cover 2 SEE CHART SEE CHART SEE CHART SEE CHART SEE CHART SEE CHART
