Parts list – Peerless-AV PLA50 - Installation User Manual
Page 3
3 of 10
ISSUED: 05-03-06 SHEET #: 202-9127-4 06-29-11
Before you start make sure all parts listed are included with your product.
A
Some parts may appear slightly different than illustrated.
B
C
D
E
F
H
I
J
K
L
M
N
O
S
P
T
G
R
U
Q
W
PLA50
PLA50-S
Description
Qty Part #
Part #
A wall plate
1
201-1095
201-4095
B tilt
ll
bl
1
201 1093
201 4093
Parts List
B tilt-roll assembly
1
201-1093
201-4093
C arm assembly
1
201-1094
201-4094
D wall support arm axle
1
201-1041
201-1041
E vinyl trim
3
600-1012
600-1012
F M10 x 15 mm screw bolt
8
520-9262
520-9262
G .505 x .75 x .062" nylon washer
1
540-1074
540-1074
H tilt adjustment knob
1
560-0108
560-0108
I
carriage bolt 3/8"-16 x 3-1/4"
1
520-1315
520-1315
J
1.525 x 2 x .062" delrin washer
2
540-1070
540-1070
K #8-32 x .375" socket head cap screw
1
520-1210
520-1210
L plastic finishing cap
8
590-1123
590-1123
M holding pin
1
580-1166
580-1166
N retainer plug
1
590-1007
590-1007
N retainer plug
1
590-1007
590-1007
O 5/16 x 3" wood screw
6
520-1243
520-1243
P .250 x 1 x .068" washer
6
540-1063
540-1063
Q 9/64" allen wrench
1
560-9728
560-9728
R cable management clips
4
590-1166
590-1166
S cable tie
4
590-1168
590-1168
T 36" polyester mesh sleeve
1
600-1015
600-1015
U 6 mm allen wrench
1
560-9716
560-9716
W anchor
6
590-0321 590-0321
