3 of 21 ISSUED: 08-09-10 SHEET #: 061-9057-5 03-04-11
D
A
B
C
Parts may appear slightly different than illustrated.
Before you begin, make sure all parts shown are included with your product.
E
F
FPEWM FPEWM-B
Description Qty. Part # Part #
A wall box 1 061-7350 061-T1350
B tilt plate 1 061-7351 061-T1351
C M10 x 16 mm socket screw 4 520-5013 520-5013
D split lock washer 4 540-5001 540-5001
E 1/4-20 x 3/4" socket cap screw 6 520-5034 520-5034
F nylock nut 6 530-5007 530-5007
G washer 6 540-5014 540-5014
Parts List
G
