Peerless-AV FPEWM - Installation - Manual (Page 2)

2 of 21 ISSUED: 08-09-10 SHEET #: 061-9057-5 03-04-11
NOTE: Read entire instruction sheet before you start installation and assembly.
Table of Contents
Parts List.................................................................................................................................................................................3
Installation to Wood Stud Wall ................................................................................................................................................4
Installing Tilt Plate to Main Enclosure Assembly ....................................................................................................................5
Mounting Main Enclosure Assembly.......................................................................................................................................6
• Do not begin to install your Peerless product until you have read and understood the instructions and warnings
contained in this Installation Sheet. If you have any questions regarding any of the instructions or warnings, for US
customers please call Peerless customer care at 1-800-865-2112, for all international customers, please contact
your local distributor.
• This product should only be installed by someone of good mechanical aptitude, has experience with basic building
construction, and fully understands these instructions.
• Due to outdoor environmental conditions such as strong wind gusts, heavy snow, hail, rain, etc. The environmental
enclosure mount, together with the enclosure, extension tube and hardware, must be inspected at least once a
year, and immediately following any time winds exceed 90 mph. A qualifi ed installer or inspector must check for
signs of rust, loose fasteners, bent metal, etc. If evidence of excessive wear, deterioration or any unsafe condition
is observed, this product must be taken out of service immediately. Direct all inquiries to customer care if you have
any questions.
• Make sure that the supporting surface will safely support the combined load of the equipment and all attached
hardware and components.
• Never exceed the Maximum Load Capacity. See page one.
• If mounting to wood wall studs, make sure that mounting screws are anchored into the center of the studs. Use of
an "edge to edge" stud fi nder is highly recommended.
• Always use an assistant or mechanical lifting equipment to safely lift and position equipment.
• Tighten screws fi rmly, but do not overtighten. Overtightening can damage the items, greatly reducing their holding
power.
• This product was designed for use with other outdoor products only.
• This product was designed to be installed on the following wall construction only;
WALL CONSTRUCTION HARDWARE REQUIRED
• Wood Stud Included with Peerless ® Outdoor Enclosure
• Wood Beam Included with Peerless ® Outdoor Enclosure
• Solid Concrete Contact Qualifi ed Professional
• Cinder Block Contact Qualifi ed Professional
• Brick Contact Qualifi ed Professional
• Other or unsure? Contact Qualifi ed Professional
WARNING
Tools Needed for Assembly
• stud fi nder ("edge to edge" stud fi nder is recommended)
• phillips screwdriver, 6 mm allen wrench, 3/16" allen wrench
• drill
• 5/32" (4 mm) bit for wood stud wall
• level
