Before you begin, make sure all parts shown are included with your product.
Parts List
Description Qty. Part Number
A base 1 009-1223
B column 1 009-1427
C column bracket 1 009-1424
D tilt plate 1 009-1423
E adapter plate 1 201-1110
F adapter bracket 2 201-1510
G 3/8-16 x 1" button socket cap screw 3 520-1354
H 3/8-16 x 1-1/2" button socket cap screw 4 520-1329
I 5/16-18 x 3/8" button socket cap screw 4 520-1693
J M10 lock washer 3 540-9424
K M10 x 15 mm button socket cap screw 4 520-9262
L 3/8-16 X 2-1/2" button socket cap screw 3 520-9550
M 6 mm allen wrench 1 560-9716
N 7/32" allen wrench 1 560-9715
O right leg 1 009-1295
P left leg 1 009-1296
Q caster 2 600-0044
R caster with brake 2 600-0045
S joint connector 4 530-1037
T 3/16" allen wrench 1 560-0071
U top plate 1 201-1724
V bottom plate 1 201-1699
W rubber feet (pack of four) 1 570-1036
X M8 x 15mm socket pin screw 4 520-1068
Y M10 x 15mm penta-pin screw 4 520-9263
Z M10 penta-pin tool 1 520-9260
AA 4mm allen wrench 1 560-9646
Parts may appear slightly different than illustrated.
