15
Password is case sensitive with a maximum length of 16 characters. After the system
validates the username and password, the Main Menu is displayed.
Main Menu
From the main menu, the end-user can view essential unit configuration data—
including active alarms in order of importance—and a clock indicating when the
displayed information was last refreshed.
Menu Options
1 = Refer to the Unit Configuration Screen
2 = Refer to the Port Alarm Status screen
3 = Refer to the SFP Line Status screen; SFP DDMI alarms are also displayed
4 = Refer to the Ethernet Port Configuration screen
5
= Refer to the Ethernet Port Status screen
6 = Refer to the E1 Port Configuration screen
7 = Refer to the E1 Port Status screen
8 = Log out
NOTE
On all configuration screens, the title is the same as the "option" selected from the
previous screen.
