THE INDUSTRIAL NETWORK COMPANY
BENEFITS
Industrial Network Switch
• Compact Size, Small Footprint
• Extended Environmental Specifi cations
• High Reliability/Availability
• Extended Environmental Specifi cations
• Hardened Metal DIN-Rail Enclosure
• High Performance
• High MTBF >2M Hours (measured)
Ease of Use
• Plug & Play Operation
• Four Auto Sensing 10/100BaseTX RJ-45 Ports
• RJ-45 Ports Auto Sense Duplex, Speed, and
Cable Type
• Compact DIN-Rail Package
Increased Performance
• Full Wire Speed Capable
• Two 100BaseFX Fiber Uplinks
• Full Duplex Capable
• Eliminates Network Collisions
• Increases Network Determinism
Regulatory Approvals
FCC Title 47 Part 15 Class A, ICES-003-Class A,
CE: EN61000-6-2, EN61000-3-2,3; IEC61000-4-2,3,4,5,6,11
EN55011
UL/cUL: Hazardous and Non-Hazardous Locations
Class I Div 2, Groups A, B, C, D , T4A and
ANSI/ISA 12.12.01-2000
Designed to comply with:
IEEE 1613 for Electric Utility Substations,
NEMA TS1/TS2 for Traffi c Control Equipment
SPECIFICATIONS
Case Dimensions
Height: 3.5"
(8.9 cm)
Width: 1.50" (3.8 cm)
Depth: 3.6" (9.0 cm)
Weight: 0.60 lbs. (0.27 kg)
DIN-Rail: 35mm
Electrical
Input Voltage:
10-30 VDC
Input Current: 330mA@24V
Inrush: 7.9Amp/0.7ms@24V
Environmental
Operating Temperature: -40
o C to 70 o C
Storage Temperature: -40 o C to 85 o C
Operating Humidity: 10% to 95%
(Non Condensing)
Operating Altitude: 0 to 10,000 ft.
Network Media
10BaseT: >Cat3
Cable
100BaseTX: >Cat5 Cable
100BaseFX:
Multimode:
50-62.5/125µm
Singlemode: 7-10/125µm
Connectors
10/100BaseTX:
Four (1) RJ-45 TX Ports
100BaseFX: Two (2) ST or SC Duplex Ports
Recommended Wiring Clearance
Front:
5" (12.7 cm)
Top: 1" (2.54 cm)
Ordering Information
106FX2-XX 100BaseFX multimode fi ber
106FXE2-XX-YY 100BaseFX singlemode fi ber
NTPS-24-1.3 DIN-Rail Power Supply
[email protected] Amp
Where "XX" is: ST for ST style fi ber connector
SC for SC style fi ber connector
Where "YY" is: 15 for 15km max. fi ber segment length
40 for 40km max. fi ber segment length
80 for 80km max. fi ber segment length
Fiber Transceiver Characteristics
Fiber Length 2km* 15km** 40km** 80km**
TX Power Min -19dBm -15dBm -5dBm -5dBm
RX Sensitivity Max -32dBm -29dBm -34dBm -34dBm
Wavelength 1310nm 1310nm 1310nm 1550nm
* Multimode Fiber Optic Cable
** Singlemode Fiber Optic Cable
