Specifications
•
10-30 VDC power input with removable terminal blocks
•
Serial connections: MES1A: DB9; MES1B: terminal block
•
Auto detecting 10/100 Mbps Ethernet RJ-45 port
•
LED indicator provides at-a-glance operation
•
Configuration via telnet console
•
Password protected
•
Operating temperature: -20 to 80 Cº
Models: MES1A, MES1B
Manual: Paper copy of this manual, PDF available
CD-ROM disc: XPort Device Installer software; PDF of MES1A/MES1B User Manual; PDF of Quick Start guide
Operating Systems Supported Windows 98/ME/2000/XP/NT 4.0 (call B&B Tech Support for other operating systems)
Dimensions MES1A/MES1B – 1.25 x 4.5 x 4.75 in (3.2 x 11.3 x 12.2 cm)
Power Supply Requirements: 10 VDC to 30VDC @ 3.6W
Power Supply: Not included
Power Connector: Removable screw terminal (2) block with screw down
Power Consumption: 12VDC @ 300 mA
Operating Temperature: -20 to 80 °C (-4 to 176 °F)
Storage Temperature: −40 to 85 °C (−40 to 185 °F)
Humidity: 10% to 90% R.H. non-condensing
Approvals: CE, FCC Class B
Link Integrity Indicator: Green/Orange LED (on Ethernet connector)
Activity Indicator: Green/Orange LED (on Ethernet connector)
Power Indicator: Red LED
Reset Switch Recessed momentary switch, press for 1 second to reboot (hardware reset)
Ethernet Connector: Single RJ-45 female (with built-in LED indicators)
Ethernet Standards Supported: IEEE 802.3 10/100 Mbps auto-detecting, 10BaseT, 100BaseTX
Protocols Supported: TCP, UDP, DHCP, SNMP, TELNET, ICMP, ARP, TFTP, Modbus ASCII, Modbus RTU, Modbus/TCP
Serial Protection: 12V TVS for MES1A; 5 V TVS for MES1B
Serial Connector: MES1A - 9 pin D-type male (DB-9M)
MES1B – removable screw terminal (5) block with screw down
Interface Lines Supported: MES1A – RS-232 TD, RD, GND
MES1B – RS-422/485 TDA(-), TDB(+), RDA(-), RDB(+), GND
Serial Data Rates: 300, 600, 1200, 2400, 3600, 4800, 9600, 19200, 38400, 57600, 115200 bps
Parity: None, Even, Odd
Data Bits: 7 or 8
Stop Bits: 1, 2
Flow Control: None
Configuration Modes: Telnet, XPort Device Installer with integrated Telnet
Device Management: SNMP – RFC 1213/1215/1316/131
IP Address Assignment: Static IP or DHCP (IP is set to 0.0.0.0)
Accessories: DIN/Panel mount bracket
