Ultra compact ethernet serial servers, Vesp211 series

background image

ultra compact Ethernet serial servers

VESP211 Series

VESP211 Serial Servers connect serial devices (RS-232, RS-422 or
RS-485) to Ethernet networks, allowing the serial device to become a node
on the network. The serial port can be accessed over a LAN/WAN using
Direct IP Mode, Virtual COM Port, or Paired Mode connections. VESP211
Serial Servers feature 10BaseT or 100BaseTX copper network. The product
is built for use in industrial environments, featuring a heavy duty metal
enclosure that is panel (standard) or DIN rail mountable (with optional
adapter). The product operates from a range of DC power supply voltages
and features a barrel connector.

ease of use
Configuration, upgrades and monitoring are simple, easy tasks with Vlinx

Manager Software. It installs right on your PC giving you access to the
serial server via your desktop. Manage remotely over a LAN or WAN via the
built-in web server. This is helpful for off-site troubleshooting and can be
done with a simple web browser.

• Ultra compact design fits into the tightest spaces
• RS-232, RS-422/485, and RS-232/422/485 models
• Wide operating temperature (-40 to 80°C)
• Wide voltage input (10 to 30VDC)
• IP30 metal enclosure
• Heavy industrial 61000-6-2 EMC Level 3 tested for

harsh environments

accEssorIEs

EIRSP1 - Industrial Ethernet Surge Suppressor
232NM9 - Null Modem Crossover Cable for DTE to DTE connection
DRAD35 - DIN Rail Adaptor Clip (pair)
PS12VDC1A - Replacement Power Supply

Product FEaturEs

ordErIng InFormatIon

Model nuMber

serial

ProtoCol

serial Port ethernet

Ports

ethernet

ConneCtor

us Power supply
VESP211

RS-

232/422/485 DB9M

1

RJ45

VESP211-232

RS-232

DB9M

1

RJ45

VESP211-485

RS-422/485

Removable

Terminal Block 1

RJ45

european Power supply - (eu)
VESP211-EU

RS-

232/422/485 DB9M

1

RJ45

VESP211-232-EU

RS-232

DB9M

1

RJ45

VESP211-485-EU

RS-422/485

Removable

Terminal Block 1

RJ45

united kingdom Power supply - (uk)
VESP211-UK

RS-

232/422/485 DB9M

1

RJ45

VESP211-232-UK

RS-232

DB9M

1

RJ45

VESP211-485-UK

RS-422/485

Removable

Terminal Block 1

RJ45

www

.

bb

-

elec

.

com

|

VESP211 Series_3713ds
