managed Industrial ethernet switch
2 gB rJ-45/sFP Ports, 8 Poe Ports
EIRP610-2SFP-T
sPecIFIcAtIons
regulatory
Approvals
FCC, CE, UL, NEMA TS2
UL File Number: E173795
Free Fall IEC60068-2-32
Shock IEC60068-2-27
Vibration IEC60068-2-6
ieee standards
IEEE 802.3 802.3. 10Base-T Ethernet
IEEE 802.3u 100Base-TX and 100Base-FX Fast Ethernet
IEEE 802.3ab 1000Base-T
IEEE 802.3z Gigabit Fiber
IEEE 802.3x Flow Control and Back Pressure
IEEE 802.3ad Port trunk with LACP
IEEE 802.3f Power over Ethernet
IEEE 802.3d Spanning Tree Protocol
IEEE 802.1w Rapid Spanning Tree Protocol
IEEE 802.1p Class of Service
IEEE 802.1Q VLAN Tag
IEEE 802.1x User Authentication (RADIUS)
IEEE 802.1ab LLDP
network sPeciFications
Architecture
Back-plane (Switching Fabric): 5.6Gbps
Throughput (Full-dux): 3.3Mpps@64bytes
Transfer Rate
14,880 pps Ethernet Port
148,800 pps Fast Ethernet Port
1,488,000 pps Gigibit Fiber Ethernet
Buffer 1 MB
MAC Table 8K
Flash ROM 4 MB
DRAM 32 MB
Other
Broadcast Storm Filtering
CSMA/CD
interFace
RJ-45 Ports
8 x 10/100BaseT, 2 x10/100/1000,
Auto MDI/MDI-X
CU/SFP 2 x Mini-GBIC SFP Combo Ports
LED
P1, P2 (Green) to indicate power
Fault (Red) to indicate fault
Mater (Green) to indicate ring master
Link Activity on 10/100 ports (Green)
Full Duplex / Collision (Amber)
SFP LNK/ACT (Green)
1000T LNK/ACT (Green)
1000M (Green)
FWD on PoE ports to indicate if a powered
device is connected
Poe
Ports 1 through 8
Standard
802.3af End Point Alternative A
Power Source Equipment (PSE)
Capacity 15.4W per port
Pin Assignment 1 & 2 – VCC(+), 3 & 6 – VCC(-)
soFtware Features
Management SNMP v1, v2C, v3, Web, Telnet, CLI
SNMP MIB
RFC 1215 Trap, RFC1213 MIBII,
RFC 1157 SNMP MIB, RFC 1493 Bridge
MIB, RFC 2674 VLAN MIB, RFC 1643,
RFC 1757, RSTP MIB, Private MIB, LLDP
MIB
VLAN
Port Based VLAN
IEEE 802.1Q Tag VLAN (256 entries)
VLAN ID (1 to 4096), GVRP (256 groups)
Port Trunk w/LACP 4 trunk groups / 4 trunk members
LLDP
Allows the switch to advertise its
Identification and capabilities on the LAN
Spanning Tree
802.1d Spanning Tree
802.1w Rapid Spanning Tree
X-Ring
Dual Homing, Ring Coupling, Dual Ring
topologies. Recovery time below 20mS
Quality of Service
Determined by port, tag, IPv4 type of
service, and IPv4/IPv6 different service
Class of Service
802.1p class of service, 4 priority queues
per port
Port Security
Supports 100 static MAC entries and 100 MAC Filter
entries
Port Mirror Supports TX, RX, and both packet
IGMP
IGMP Snooping v1, v2 (256 multi-cast
groups and IGMP Query
IP Security
10 IP address entries for permission to
access management functions
Login Security 802.1X Authentication / RADIUS
Bandwidth Control
Ingress Packet Filter and Egress Packet
Limit. The egress rate control supports
all packet types. Limit rates are: 100K to
102400 Kbps (10/100) and 100 K to
256000 Kbps (1000). Ingress packet
Filter Type combination rules are
Broadcast, Multi-Cast, Unknown Unicast,
Broadcast/Multi-cast, Broadcast only, and
all packets.
Flow Control Flow control full-dux, backpressure half-dux
System Log System Log and remote system log server
SMTP SMPT SVR and 6 e-mail accounts for alerts
SNMP Trap
Cold Start, Link Down, Link Up, Authorization
Fail, PD Disconnect (PoE port event)
DHCP Client, Server, Port and IP Binding
DNS
DNS client with primary and secondary
DNS server
SNTP SNTP to synchronize system clock
Firmware Update TFTP update, backup and restore
Power
Input Voltage
Dual 48 VDC Inputs
Reverse Polarity Protection
Power Connection Removable Terminal Block
Wire Size 12 to 24 AWG
Power Use
9.6 Watts (Without PoE Load)
116 Watts (Full PoE Load)
Fault Output 1 Relay Output – Normally Closed
enVironMental
Operating Temperature - 40 to 75°C (-40 to 167°F)
Storage Temperature - 40 to 85°C (-40 to 185°F)
Operating Humidity 0 to 95%
Mechanical
Enclosure IP30 Metal Enclosure
Mounting 35 mm DIN Rail or Panel Mount Attachments
Dimensions 6.2 x 8.4 x 13.1 cm (2.44 x 3.31 x 5.16 in)
