1
About the IE-ModeConverter
The IE-ModeConverter is a pure media (mode) converter that converts any fiber
optics type to any other fiber optics type. It is a PHY-to-PHY protocol and speed
independent converter and is not intended for applications that require retiming or
any Layer 2 functions. The IE-ModeConverter supports extended temperature
operation. This product is applicable to Ethernet, SONET, and Fiber Channel
applications.
The IE-ModeConverter requires two small form-factor (SFP) modules (sold separately),
which provide greater fiber flexibility in the network environment. The hot-
swappable nature of the SFPs and the numerous fiber modes and types available in
SFPs allow for easy configuration and future upgrading as network demands evolve.
The SFP modules must be MSA compliant and support the same speed range.
The IE-ModeConverter operates as a mode converter only and not as a rate
converter.
The IE-ModeConverter does not provide support for copper SPFs.
Features
The IE-ModeConverter provides the ability to change optical transport characteristics
using easy-to-install SFP devices. This mix-and-match functionality is only limited by
the available IMC Networks’ SFP units. For more information about SFPs, visit
https://www.imcnetworks.com/Products/Small_Form_Factor_Pluggable.cfm
The key features of the IE-ModeConverter are
• Uses the MiniMc Form Factor
• Supports a 7VDC to 50VDC terminal block option with cascading power
• Supports an external 5VDC power option (not extended temperature)
• Allows extended temperature range from -31° to 158° F (-35° to 70° C)
• Uses all standard MSA-complaint SFP devices (excluding copper SFPs)
• Provides extensive diagnostic LED functions
• Supports LinkLoss functionality
• Supports DIN Rail mounting
Applications
The standard application is the conversion of a short-range, multi-mode fiber
interface to a long-range single-mode fiber line. In addition, CWDM, DWDM, or
single-strand fiber can be supported with the appropriate SFP. This allows you to
purchase low cost multi-mode fiber blade cards for your network equipment and
support long-distance single-mode fiber links.
