Command Descriptions
Set ID
Description Assign an ID of up to 24 bytes to the
module at address AA.
Data Pass
Description Tell the module at address AA to pass up
to 32 bytes of data to the RS-232 device.
Syntax
Response
Example
(delimiter)AA(data) (cr)
depends on the device
command: {24#02 (cr)
response:
The command asks the module at
address 24h to send #02 (cr) to the RS-
232 communication port.
Syntax
Response
Example
$AA6(identification) (cr)
!AA (cr) if the command is valid.
command: $246ADAM NETWORK 1 (cr)
response: !24 (cr)
The command asks the module at
address 24h to write "ADAM NETWORK
1" to EEPROM.
Read ID
Description Read the ID from the module at address
AA.
Syntax
Response
Example
$AA7 (cr)
!AA(identification) (cr)
command: $247 (cr)
response: !24ADAM NETWORK 1 (cr)
The command asks the module at
address 24h to return the identification
data from EEPROM.
Set Delimiter
Description set the delimiter character for the Data
Pass command. There are 8 special
characters to choose from:
: [ ] ^ { | } ~
Syntax
Response
Example
$AAC(delimiter) (cr)
!AA (cr) if the command is valid
command: $24C{ (cr)
response: !24 (cr)
The command asks the module at
address 24h to write delimiter character
{ to EEPROM.
Read Delimiter
Description Read the delimiter character from the
module at address AA.
Syntax
Response
$AAD (cr)
!AA(delimiter) (cr) if the command is
valid. (delimiter) is a character for the
Data Pass command.
command: $24D (cr)
response: !24{ (cr)
The command asks the module at
address 24h to return the delimiter
character from EEPROM.
Example
