8 Port gigabit Industrial ethernet switch

EIR408-T

The EIR408-T is an 8 Port Unmanaged Industrial Gigabit Ethernet Switch.
Packed full of rugged features, this switch is perfect for your high speed
industrial network.

high-speed transmissions: The EIR408-T includes a switch controller
that automatically senses transmission speed (10/100/1000 Mbps).
The RJ-45 interface also auto-detects MDI or MDI-X, eliminating the
requirement for a crossover cable. Each port is buffered and supports
store-and-forward protocol.

dual Power input: To reduce the risk of power failure, the EIR408-T
provides two 12 to 48 VDC power inputs. If the power fails, the switch will
automatically use the secondary power input. Also, if the power goes out
the corresponding P1 or P2 LED will go out and the Fault LED will light.
The contacts for the alarm output will also open.

Flexible Mounting: The switch features a space saving IP30 metal
enclosure that can be DIN or Panel mounted.

wide operating temperature: With an operating temperature of -40
to 75°C (-40 to 167°F), this switch can be used in harsh industrial
environments.

easy troubleshooting: There are two LED indicators for each port that
display the link status and transmission speed. Three LED indicators
for power (P1, P2 and Fault) show power status. These indicators allow
you to quickly diagnose and correct problems and ensure your network
remains reliable.

• 8 10/100/1000 Base-T Ethernet ports
• UL Class 1/Division 2
• NEMA TS2
• Dual 12 to 48 VDC power inputs
• Wide operating temperature (-40 to 75°C)

Product FeAtures

AccessorIes

C5UMB7FBG - Category 5e, 7 ft. (2.1 M), Grey

EIRSP1 - Industrial Ethernet Surge Suppressor

MDR-20-24 - DIN rail mount power supply 24VDC, 1.0 A output power

MDR-40-24 - DIN rail mount power supply 24VDC, 1.7 A output power

MDR-60-24 - DIN rail mount power supply 24VDC, 2.5 A output power

orderIng InFormAtIon

Model nuMBer

descriPtion

EIR408-T

8 Port Industrial Gigabit Switch

EIR408-T_3713ds
