Troubleshooting
Are My Devices Wired As DTE or DCE?
How to Check:
1. Use Rule of Thumb - If the device plugs into
the computer serial port and works normally,
the device is wired as DCE (or the connection cable
is a crossover type that makes it work as a DCE).
If the device connects to the computer port using
a “null modem” crossover cable, it is wired as DTE.
2. Use RS-232 Line Tester - A quick and easy way
to determine the DTE/DCE port type is to use
a RS-232 line tester such as the 9PMTT. The tester
can show the signal state of any active RS-232
data lines using LEDs lighting Red or Green.
Active data lines are output from a device.
They may be either High or Low.
Information – UL Class 1 Div 2
1. Power, input /output (I/O) wiring must be in
accordance with Class 1 Division 2 wiring
methods [Article 501.10(B) of the National
Electric code, NFPA70] and in accordance
with the local authority having jurisdiction.
2. Maximum ambient air temperature 80°C.
3. WARNING – EXPLOSION HAZARD:
SUBSTITUTION OF ANY COMPONENTS MAY IMPAIR
SUITABLITY FOR CLASS 1, DIVISION 2.
4. WARNING – EXPLOSION HAZARD: WHEN IN
HAZARDOUS LOCATIONS, TURNING OFF POWER
BEFORE REPLACING OR WIRING MODULES.
5. WARNING – EXPLOSION HAZARD: DO NOT
DISCONNECT EQUIPMENT UNLESS POWER
HAS BEEN SWITCHED OFF OR THE AREA
IS KNOWN TO BE NON-HAZARDOUS.
6. WARNING – THIS APPARATUS IS SUITABLE
FOR USE IN CLASS 1 DIVISION 2, GROUPS
A, B, C, AND D, OR UNCLASSIFIED.
Document number – p/n 8457 r003 232OPDRi - 1512
© 2012 B&B Electronics Manufacturing Company
1-888-948-2248 | Europe: +353 91 792444
www.bb-elec.com
Recommended Accessories
and Power Supplies
Surge Protector
Industrial Power Supply
232HESP
MDR-20-24
707 Dayton Road | PO Box 1040 | Ottawa, IL 61350
Phone: 815-433-5100 | Fax: 815-433-5109
www.bb-elec.com | E-mail: [email protected]
http://www.bb-elec.com/232OPDRI
Fast and easy on the web: www.bb-elec.com
ILinx 232OPDRI Isolated Repeater
Additional items required but not included:
(1) 10 to 48 VDC Power Supply
Two RS-232 Cables
Ground Cable
First Things First...
Before you begin, be sure you have
the following:
RS-232 Repeater with Triple Isolation
232OPDRI
http://www.bb-elec.com/232OPDRI/
ACC
http://www.bb-elec.com/232OPDRI/
ACC
Fast, Easy Answers
• First, check step 2.
• Then use your smart
phone to access complete
documentation on our
web site. Simply scan
the code to the right.
