Specifications
RANGE
Direct Connect Up to 100m (330 ft) over solid core Cat 5e or better
USB DEVICE SUPPORT
Maximum USB 2.0 Throughput Up to 480Mbps
Maximum USB 1.1 Throughput Up to 12Mbps
Traffic Types All USB 2.0 and 1.1 Traffic Types
Device Types All USB 2.0 and 1.1 Device Types
Number of Devices and/or Hubs 17
LOCAL EXTENDER (LEX)
USB Connector 1 x USB 2.0 Type B Receptacle
Link Connector 1 x RJ45
Dimensions 100mm x 76mm x 26mm (3.9” x 3.0” x 1.0”)
Enclosure Material Silver Anodized Aluminum
REMOTE EXTENDER (REX)
USB Connectors 4 x USB 2.0 Type A Receptacles
Link Connector 1 x RJ45
Dimensions 100mm x 76mm x 26mm (3.9” x 3.0” x 1.0”)
Enclosure Material Silver Anodized Aluminum
Available Current 600mA at each USB port concurrently
Power Supply 100-240V AC input, 24V 1A DC Output
ENVIRONMENTAL
Operating Temperature Range 0°C to 50°C (32°F to 122°F)
Storage Temperature Range -10°C to 60°C (14°F to 140°F)
Operating Humidity 20% to 80% relative humidity, non-condensing
Storage Humidity 10% to 90% relative humidity, non-condensing
COMPLIANCE
EMC FCC (Class B), CE (Class B)
Environmental RoHS2 (CE)
SUPPORT
Warranty 2 years
