Troubleshooting
Self-diagnostic Test Procedure
1. Two Ethernet extenders are connected, as a pair,
using BNC connectors over coaxial cable.
2. One Ethernet extender is configured as a local
unit. The setting mode switch on the rear panel of this
Ethernet extender is set to Loc (local mode), and is
located at the local end of the Ethernet extension.
3. The other Ethernet extender is configured as the
remote unit. The setting mode switch on the rear
panel of this Ethernet extender is set to Rmt (remote
mode), and is located at the remote end of the Ethernet
extension.
4. Supplied AC to DC power adaptors are connected
to the receptacles on the rear panel of both Ethernet
extenders. Both adapters are plugged into standard
AC outlet sockets.
5. LED 5 on the top panel of both Ethernet extenders
lights up in an amber or green color, showing
that both Ethernet extenders are connected and
have negotiated best performance for symmetrical
transmission.
Document number – p/n r002 EIS-EXTEND-C - 1712
Recommended Accessories
and Power Supplies
Power Supply for EIS-RACK-16,
84 Watts
CAT 5 Cable
EIS-RACK-PS
CAT 5 Cable
