Industrial Poe ethernet extender
EIRP-EXTEND
sPecIFIcAtIons
technology
Standards: 802.3 10BaseT
802.3u 100BaseTx
802.3x
Ethernet over VDSL
Protocol Transparent to higher level
Protocols
Processing Half-duplex: back pressure
Full-duplex: 802.3x
Power
Input Voltage 48 VDC – Power Jack
24 - 48 VDC Terminal Block
Power Consumption 38.4 W Max, 0.8A@48VDC
Mechanical
Case DIN Mount IP30 Aluminum
Dimensions
50 mm (W) x 110 mm (D) x 135 mm (H)
1.97” (W) x 4.33” (D) x 5.31” (H))
Weight 0.8 kg (1.76 lbs)
ethernet interFace
Ports PoE RJ-45, 10/100BaseTX
Full/Half Duplex
Auto-Negotiation
Auto-MDI/MDX
PoE Plus Complies with IEEE802.3af / 802.3at standard
Speed 10/100 Mbps
Distance 320 ft. (100 m)
Cable 100Base-TX UTPCAT 5 (4 pair)
extender interFace
Port One RJ-11 or Terminal Block
Speed Up to 50 Mbps
Distance Up to 6,232 ft. (1.9 km)
Cable
24 AWG Copper Pair (0.5mm diameter, 1 pair wire)
or larger 100 Ohm impedance
enVironMent
Operating Temperature -40 to 75° C
Tested to 85° C
Storage Temperature -40 to 85° C
Operating Humidity 5% to 95% Non-condensing
led chart
1
Green 1 Mbps 6232 ft. (1.9 km)
Amber 3 Mbps 5904 ft. (1.8 km)
2
Green 5 Mbps 5249 ft. (1.6 km)
Amber 10 Mbps 4593 ft. (1.4 km)
3
Green 15 Mbps 3936 ft. (1.2 km)
Amber 20 Mbps 3280 ft. (1.0 km)
4
Green 25 Mbps 2624 ft. (0.8 km)
Amber 30 Mbps 2296 ft. (0.7 km)
5
Green 40 Mbps 1968 ft. (0.6 km)
Amber 50 Mbps 984 ft. (0.3 km)
regulatory aPProVals
ISO Manufactured in an ISO9001 facility
Safety UL508
EMI
• FCC Part 15, Class A
• EN61000-6-4
• EN55022
• EN61000-3-2
• EN61000-3-3
EMS
EN61000-6-2
• EN61000-4-2 (ESD Standards)
- Contact: + / - 4KV; Criteria B
- Air: + / - 8KV; Criteria B
• EN61000-4-3 (Radiated RFI Standards)
- 10V/m, 80 to 1000MHz; 80% AM Criteria A
• EN61000-4-4 (Burst Standards)
- Signal Ports: + / - 4KV; Criteria B
- D.C. Power Ports: + / - 4KV; Criteria B
• EN61000-4-5 (Surge Standards)
- Signal Ports: + / - 1KV; Line-to-Line; Criteria B
- D.C. Power Ports: + / - 0.5KV; Line-to-earth; Criteria B
• EN61000-4-6 (Induced RFI Standards)
- Signal Ports: 10Vrms @ 0.15 - 80MHz; 80% AM Criteria A
- D.C. Power Ports: 10Vrms @ 0.15 - 80MHz; 80% AM
- Criteria A
• EN61000-4-8 (Magnetic Field Standards)
- 30A/m @ 50, 60Hz; Criteria A
Environmental
Test Compliance
• IEC60068-2-6 Fc (Vibration Resistance)
- 5g @ 10 - 150Hz, Amplitude 0.35mm
(Operation/Storage/Transport)
• IEC60068-2-27 Ea (Shock)
- 25g @ 11ms (Half-Sine Shock Pulse; Operation)
- 50g @ 11ms (Half-Sine Shock Pulse; Storage/Transport)
• IEC60068-2-32 Ed (Free Fall)
- 1M (3.281ft.)
installation:
• DIN Rail (35mm) Panel Mount, Rack Mounting with optional kit.
