Industrial hardened 10/100base-tx
to 100base-Fx media converters
EIR-x-Sx Series
Media converters convert twisted pair copper signals to fiber optic
signals. LANs can be extended beyond the normal 100 meter limit up
to 2km with multimode fiber and up to 20km with single-mode fiber.
Since your data is traveling via fiber, it is protected from ground loop
problems and electrical interference present along the cable run.
Extension of LAN distances make it possible to communicate with
remotely located Ethernet enabled devices. The application could be
as simple as getting data from one end of the warehouse to the other,
tying two buildings together, enabling communications on a tank farm,
or monitoring a SCADA system at a waste water plant.
Extended temperature and voltage specifications allow installation in
the toughest environments. Media converters are highly qualified for
environmental 10/100BASE Ethernet applications and certified by UL
with ISA12.12.01 Class I, Division 2 for use in hazardous locations.
• Class 1/Division 2
• NEMA TS1/TS2 requirements for traffic control equipment
• IEC61000-6-2 EMC generic standard immunity for industrial
environments
• Rugged DIN rail metal cases (panel mount kit available)
• Wide temperature range ( -34 to +74 ºC)
• Alarm for power or port link failure via relay output (dry contact)
• Redundant 10 to 48 VDC power inputs (via terminal blocks)
• Vibration Resistance, Shock, Free Fall
product FEaturEs
ordErIng InFormatIon
Model nuMBer 10/100 CoPPer FiBer
distanCe Class 1/
division 2
EIR-M-ST
1 (RJ-45)
Multi-mode (ST)
2 km
X
EIR-M-SC
1 (RJ-45)
Multi-mode (ST)
2 km
X
EIR-S-SC
1 (RJ-45)
Single-mode (SC) 20 km
X
accEssorIEs
ERS35 - DIN Rail 1 Meter 35MM Steel
C5UMB3FBG - 3 ft - Beige - Category 5e UTP Patch Cord Assemblies
DR-30-24 - DIN rail mount power supply, 24 VDC, 1.5 A power output
MDR-40-24 - DIN rail mount power supply 24VDC, 1.7 A output power
