Industrial dIn rail mount
ethernet extender
EIR-EXTEND
extender interFace
Port RJ-11 or Terminal Block
Speed Up to 50 Mbps
Distance Up to 6,232 ft. (1.9 km)
Cable 24 AWG Copper Pair 100 Ohm Impedance
enVironMent
Operating Temperature -40 to 75ºC Tested to 85ºC
Storage Temperature -40 to 85ºC
Operating Humidity 0 to 95% Non-condensing
regulatory aPProVals
Emissions FCC Part 15, Class A, NEMA TS2
CE EN61000-6-(2,3)
EN6100004-(2,3,4,5,6,8,11)
UL/CUL Class 1/Division 2 Groups A, B, C, D
sPecIFIcAtIons
technology
Standards
802.3 10BaseT
802.3u 100BaseTx
802.3x
Ethernet over VDSL
Protocol
Transparent to higher level
Protocols
Processing
Half-duplex: backpressure
Full-duplex: 802.3x
Power
Input Voltage
12 VDC – Power Jack
12 – 30 VDC Terminal Block
Input Connection
350 mA (Power Jack)
175 mA (Terminal Block)
Power Consumption 4.2 W Max
Mechanical
Case DIN Mount IP30 Aluminum
Dimensions 5.0 x 11.12 x 13.5 cm (1.97 x 4.38 x 5.31 in)
Weight 0.8 kg (1.76 lbs)
ethernet interFace
Port
RJ-45, 10/100BaseTX
Full/Half Duplex
Auto-Negotiation
Auto-MDI/MDX
Speed 10/100 Mbps
Distance 320 ft. (100 m)
Cable CAT 5
toP leds (Bnc line connections)
led speed distance
1 Green
1 Mbps 6232 ft. (1.9 km)
Amber 3 Mbps 5904 ft. (1.8 km)
2 Green
5 Mbps 5249 ft. (1.6 km)
Amber 10 Mbps 4593 ft. (1.4 km)
3 Green
15 Mbps 3936 ft. (1.2 km)
Amber 20 Mbps 3280 ft. (1.0 km)
4 Green
25 Mbps 2624 ft. (0.8 km)
Amber 30 Mbps 2296 ft. (0.7 km)
5 Green 40 Mbps 1968 ft. (0.6 km)
Amber 50 Mbps 984 ft. (0.3 km)
