Industrial dIn rail mount ethernet extender
EIR-EXTEND
The EIR-EXTEND is a point-to-point Ethernet Extender designed to
operate in harsh environments. Functioning at temperatures from -40
to 75º C, it has been tested for functional operation up to 85º C. Using
existing copper wire runs, it allows the extension of Ethernet signals. The
EIR-EXTEND is the perfect solution for installing Ethernet connectivity
on the factory floor. Used in pairs, configuration is easy. Configure one
unit as the local device, and the other one as the remote device. External
power supplies are required (not included).
• Redundant power inputs
• Wide operating temperature
• Extend Ethernet up to 6232 ft. (1.9 km) over standard copper wires
• Ethernet port: RJ-45 10/100Mbps
• Full/Half-duplex, Auto-negotiation / Auto-MDI/MDX
• Ethernet extend port: RJ-11 50Mbps full duplex VDSL
• UL/CUL Class 1/Division 2 Groups A, B, C, D
• NEMA TS2
Product FeAtures
orderIng InFormAtIon
Model
nuMBer
ethernet
Ports
EIR-EXTEND DIN Rail Mount Ethernet Extender
AccessorIes
MDR-40-24 - DIN Rail Power supply 24VDC 40 Watt
PS12VDC3P - Hardened AC Power Supply, 12VDC, 36W, 3A, 90-264VAC input, DC jack
C5UMB3FBL - 3 ft. (1 M) - Blue - Category 5e UTP Patch Cord
Government Remote
Site Metering
Industry: Energy and Natural Resources
Product: Ethernet Extender
www.bb-elec.com/
Metering
EIR-EXTEND
Carrier data charges
may apply.
In the FIeld
Recording Wastewater
Chlorine and PH Levels
Industry: Energy and Natural Resources
Product: Ethernet Extender
www.bb-elec.com/
Wastewater
EIR-EXTEND
Carrier data charges
may apply.
In the FIeld
EIR-EXTEND_3713ds
