7506GX2 Specifi cations
Switch Properties
Number of MAC Addresses: 4000
Aging Time: Programmable
Latency Typical: 1.6 μs
Switching Method: Store-and-Forward
Case Dimensions
Height: 3.8" (9.6cm)
Width: 2.0" (5.1cm)
Depth: 3.9" (9.9cm)
Weight (max): 1.1lbs (0.48kg)
DIN-Rail Mount: 35mm
Electrical
Redundant Input Voltage: 10-49 VDC (Regulated)
Input Current (max): 440mA max.@24VDC
N-TRON Power Supply: NTPS-24-1.3 (1.3A@24V)
Environmental
Operating Temperature: -40 o C to 80 o C
Storage Temperature: -40 o C to 85 o C
Operating Humidity: 5% to 95%
(Non Condensing)
Operating Altitude: 0 to 10,000 ft.
Shock and Vibration (bulkhead mounted)
Shock: 200g @ 10ms
Vibration/Seismic: 50g, 5-200Hz, Triaxial
Reliability
MTBF: >2 Million Hours
Recommended Wiring Clearance
Front: 4" (10.16 cm)
Side: 1" (2.54 cm)
Network Media
10BaseT: >Cat3 Cable
100BaseTX: >Cat5 Cable
1000BaseT: >Cat5e Cable
Connectors
10/100/1000BaseT(X): Four (4) RJ-45 Copper Ports
1000BaseT:
Up to Two (2) RJ-45 Gigabit
Copper Ports (optional)
1000BaseSX/LX: Up to Two (2) LC Duplex Gigabit
Fiber Ports (optional)
Regulatory Approvals
FCC Title 47, Part 15, Subpart B - Class A; ICES-003 - Class A
CE: EN61000-6-2:2001; EN61000-6-4:2007
EN61000-4-2, 3, 4, 5, 6
GOST-R Certifi ed, RoHS Compliant
Designed to comply with:
UL Listed (US and Canada) 1604; ANSI/ISA-12.12.01-2007
Class I, Div. 2, Groups A, B, C, D, and T4A
IEEE 1613 for Electric Utility Substations
NEMA TS1/ TS2 for Traffi c control
7506GX2 Industrial Ethernet Switch Ordering Information
7506GX2 Four 10/100/1000BaseT(X) Ports and two SFP ports without (optional) modules
7506GX2-SX Four 10/100/1000BaseT(X) Ports and two SFP ports with 2 NTSFP-SX Multimode modules installed
7506GX2-LX-10 Four 10/100/1000BaseT(X) Ports and two SFP ports with 2 NTSFP-LX-10 Singlemode modules installed
NTSFP-TX Optional SFP (Mini-GBIC) Transceiver with One 1000BaseT GB Copper Port
NTSFP-SX Optional SFP (Mini-GBIC) Transceiver with One 1000BaseSX Multimode GB Fiber Optic Port
NTSFP-LX-ZZ Optional SFP (Mini-GBIC) Transceiver with One 1000BaseLX Singlemode GB Fiber Optic Port
NTCD-128 Optional SD Card, Confi guration Device
NTPS-24-1.3 N-TRON Power Supply - (1.3 Amp @ 24VDC)
1000-PM Panel Mount kit
URMK Universal Rack Mount Kit
Where: ZZ = 10, 40, or 70 for GB Singlemode
THE INDUSTRIAL NETWORK COMPANY
Contact Information
N-TRON Corp. N-TRON Asia N-TRON Europe GmbH
820 S. University Blvd., Suite 4E Unit 1209, Level 12 Alte Steinhauserstr 19
Mobile, AL 36609 USA Chong Hing Finance Center 6330 Cham / Zg Switzerland
TEL: (251) 342-2164 288 Nanjing Road West TEL: +41 41 7406636
FAX: (251) 342-6353 200003 Shanghai FAX: +41 41 7406637
Website: www.n-tron.com P.R. China
Email: [email protected] TEL: +86-021-6133-7770
FAX: +86-021-6133-7999
SFP Gigabit Fiber Transceiver Characteristics
* SX Fiber Optic Cable
** LX Fiber Optic Cable
Fiber Length 550m for 50/125μm* 10km** 40km** 70km**
TX Power Min -9.5dBm/-4dBm -9.5dBm/-3.5dBm -2dBm/3dBm 0dBm/5dBm
RX Sensitivity Max -17dBm -20dBm -22dBm -24dBm
Wavelength 850nm 1310nm 1310nm 1550nm
Assumed Fiber Loss -0.5dB/km -0.35dB/km -0.25dB/km
Laser Type VCSEL FP DFB DFB
