Daughter Board Module
Connector:
24-Pin Header
0.5mm Square Pins
2.0mm Pin Spacing
Samtec P# TMM-112-06-T-D-SM
Suggested Stand-Off:
1.750"
0.078" Max.
1.750"
0.110" Max.
2.0 mm
2 1
24 23
0.382"
ø 0.103" x4
0.075"
0.267"
